Lectric XP 4 750 Folding E-Bike

Lectric XP 4 750 Folding E-Bike overview

The Lectric XP 4 750 Folding E-Bike is set up for apartment storage, rv and travel. Power comes from a rear hub motor rated at 500 W nominal / 1,000 W peak with 55 Nm of torque, paired with a 48V 14Ah battery pack holding roughly 672 watt-hours of energy. On mixed terrain that supports up to 45 miles (pedal assist); hills, rider weight, tire pressure, temperature and assist level all change the real figure.

Motor and battery

Cadence sensing decides how much help you get, so assistance builds smoothly instead of surging. Top assisted speed is 20 mph (Class 2), and the bike is supplied as Class 2 (throttle and pedal assist). A full charge takes about 4–6 hours from a standard 110V outlet. Charge indoors, at room temperature, on the charger supplied with the bike.

Comfort and handling

The folding frame runs 20″ x 3.0″ tires with front suspension fork, and a 7-speed drivetrain for pedalling above assist speed. Claimed bike weight is 64 lb, with a 330 lb total maximum load including rider and cargo.

Braking and safety

Hydraulic disc brakes handle stopping in traffic and on descents. Check brake pads, tire pressure and battery mounting before every ride, and always ride with a helmet. Fat and wide tires improve traction on loose surfaces, but no e-bike is safe on ice.

Who this bike is for

Riders who want apartment storage, rv and travel without stepping up to a motorcycle. If you are unsure whether this frame fits you, contact us with your height and inseam before ordering and we will confirm.

Why you’ll love it

• One battery covers most everyday trips
• Hydraulic disc braking with predictable feel
• Folding frame that suits everyday use
• Serviceable, widely available parts

Specifications

Motor	Rear hub, 500 W nominal / 1,000 W peak, 55 Nm
Battery	48V 14Ah (672Wh), charge time 4–6 hours
Range	Up to 45 miles (pedal assist)
Top assisted speed	20 mph (Class 2)
E-bike class	Class 2 (throttle and pedal assist)
Brakes	Hydraulic disc
Suspension	Front suspension fork
Drivetrain	7-speed
Tires	20″ x 3.0″
Frame	Folding, aluminum alloy
Bike weight	64 lb
Maximum payload	330 lb total
Condition	New

Specifications follow the manufacturer’s published information for this model. Contact us before ordering if a specific figure is critical to your decision and we will confirm it with the supplier.

What’s in the box

Bike, battery, charger, tool kit, quick-start guide and manufacturer documentation. Accessory items shown in lifestyle photography are not included unless listed.

Assembly

Ships mostly assembled. Expect to fit the front wheel, handlebar, pedals and seat, then check brakes and torque before the first ride. See our assembly and maintenance guide, or ask us for an assembly quote.

Warranty, shipping and returns

Covered by the manufacturer warranty that applies to this model — see our warranty policy. Shipping is handled per our shipping policy, and returns per our return and refund policy.

Questions before buying?

Call +1 (213) 657-0405 or email Info@rayelectricbikes.com. We will help with sizing, class rules in your state, range for your commute and accessory fit.

Frequently asked questions

What range will I really get? Plan on the lower end of the published figure in hills, cold weather or with heavy loads.

Can I ride this on bike paths? It depends on your state and local rules — see our e-bike laws overview.

Do you help with sizing? Yes. Send us your height and inseam and we will recommend a frame.
